Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots

SMT Online 8 Heads Pick And Place Machine With 120 Feeder slots Pick And Place Robot

porduct description

The HW-DSQ800-120F is our most popular model with Vision. The HW-DSQ800-120F offers technologically advanced features with 120 single feeder positions where quick setup, easy of operation and high reliability are paramount.

System Features

* The highest quality with the most advanced equipment at a cost-effective solution

*Placement rates up to 26000 cph

*Accurately places a wide range of components including 0201, 0402, LED, BGA, QFN...


Placement rates	26000CPH
Accuracy	± .001” (0.02mm)
Voltage	220AC
Weight	1100kg
Warranty	1 year
Suppport	Video Support
UI	The best GUI (graphical user interface) in its class using Windows®-based software allows programming in minutes
Max no. of Feeders (8mm tape)	Max no. of Feeders (8mm tape)
Max Board Size	260mmX400mm
Smallest Component Capability	0201
Vision System	HWGC Vision
Vibratory Feeders	NXT Feeder, tube, stick (frequency & amplitude control)

The HW vision System assist allows accurate placement of 0201, BGA, QFN, QFP,LED and a wide range of virtually all SMT components.

Our Advantages

1.120pcs material stations -- can meet the mounting requirements of
various materials and various specifications and packages of the
product.

1) 120pcs 8mm material stations support NXT electric feeder, 12mm,
16mm, 24mm, 32mm and 44mm NXT electric feeder,,vibration feeder and
IC trays.

2)NXT electric platform specification: 8mm-44mm NXT electric
feeder, electric feeder stable feeding, high precision, long
service life.

2.8 groups of independent mounting heads - 8 groups of mounting
heads are distributed with different nozzles, which are suitable
for the mounting requirements of products with more specifications.

1) 8 groups of mounting heads can realize the double arms and four
heads pick simultaneously,pick up the material at same time, The
picking efficiency is improved greatly.

2)The mounting head can rise and fall independently, rotate from 0
to 360 degrees, and mount up to 20 mm components.

3)The z-axis can rise and fall independently according to the
thickness of the components,For the resistance and capacitance
components, the mounting head can realize the fly visual
identification, High components can be mounted at reduced speed.

4)It can meet the requirements of different sizes of components,
different specifications and different packages, achieve diversity,
one-time placement.

Pneumatic SMT Pick And Place Machine Robot 8 Heads With 120 Feeder Slots

porduct description

The HW-DSQ800-120F is our most popular model with Vision. The HW-DSQ800-120F offers technologically advanced features with 260mm x 400mm work area, 120 single feeder positions where quick setup, easy of operation and high reliability are paramount.

Vision System

The HW-series vision pick and place systems is easy to programming for all operators, Intelligent and fast to operation

Feeders

NXT Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.
