13000CPH Reflow Soldering Oven / HWGC Smd Led Making Machine

Product Categories

Beijing Huaweiguochuang Electronic Technology Co., Ltd.

Contact Now

13000CPH Reflow Soldering Oven / HWGC Smd Led Making Machine

Ask Lasest Price
Brand Name :	HWGC
Model Number :	HW-T8-80F
Certification :	CE
Price :	usd+15000+pieces
Payment Terms :	T/T
Supply Ability :	50+Pieces+Month
Delivery Time :	5-8work days

Add to Cart

Product Details
Company Profile

13000CPH Reflow Soldering Oven / HWGC Smd Led Making Machine

SMT pick and place machine uses imported Straight guide rail +screw Guide can get faster speed and more stable

Products Description

Based on 6 mounting heads +8 cameras+64 feeder positions+ Panasonic
Servo motor+guide screw, the positioning is highly developed(PRECISION:0.01MM)
SMT PNP Machine can pick 0201, 0402, 0603, 0805, 1206, diode, triode, SOT, and QFP, BGA, etc.
With lead pitch ≥0.3mm (pin center distance 0.5mm) within 40 * 40mm
.

Machine is of high quality with at least one-year warranty, lifetime maintenance.

Specification
Number of feeders	64
Number of IC tray	6
Number of cameras	8
Number of heads	6
Average power	500W
Positioning precision	0.01mm
The buffer range of suction nozzle	4.5mm
Power supply	220V, 50/60Hz
Compressed air	0.5-0.6Mpa
Drive motor	Panasonic servo motor
Vacuum source of suction nozzle	high-speed on-off vacuum generator with vacuum breaker
Maximum circuit board area	600×455mm
Maximum travel scope in Z axis	20mm
Tape feeder	8, 12, 16, 24mm and vibration suction (mounting pipe chip)
Maximum mounting speed	12000 Pcs/h
Average mounting speed of actual mounting resistance	9600Pcs/h
XYZ drive guide rail	TBI high-precision reloading linear guide rail
Motion drive system	Panasonic high-speed DSP drive
Operating system	full-automatic chip mounter operating system independently
	developed by Huawei Guochuang based on Windows
	operating systemand it supports windows xp
	win7 operating system
Element angle	0-360°, synchronous rotation during movement
X/Y operation mode	intelligent curve of the linear acceleration and deceleration linkage
MARK point positioning	full-automatic (the MARK point can be adjust at will)
Intelligent alarm	automatic correction, automatic filling, feeding shortage alarm
Plate entering mode	automatic connection from left to right in single sections
	automatic PCB transfer positioning. /plunger positioning
	manual plate feeding.
Visual display	17-inch industrial control display, 4:3, resolution: 1280 x1024
Number of recognition cameras	One Mark recognition camera, four quick-recognition cameras
Number of recognition cameras	and one precise-recognition camera

Adaptive mounting scope	Adaptive to 0201, 0402, 0603, 0805, 1206, diode, audion, SOT, QFP
	within 40*40mm and the pin distance ≥0.3mm
	(0.5mm center distance) and BGA
Product weight	500KG
Dimension	145013701550mm

Vision System

The HW-series vision pick and place systems is easy to programming for all operators, Intelligent and fast to operation

Feeders

Yamaha Pneumatic feeder and Electricial feeder were adopted, sizes include 8mm, 12mm, 16mm, 24 mm, 32mm and 44mm.
